PRODUCT details
M3043661
GR.CARC.PR.NMRV-P110 20, 0 D42 B3 MV
GR.CARC.PR.NMRV-P110 20, 0 D42 B3 MV
€ 585,90
LIMITED AVAILABILITY
Shipment Costs
-
Trasporto a mezzo corriere Bartolini BRT 0,00 €
Product details
MANUFACTURER: Motovario S.P.A.
FEATURES:
Casing kit NMRV-P110 20,0 D42 B3 MV
Worm Gearbox: NMRV Power
Size: 110
Ratio (i): 20
Hollow output shaft dim.: D.42
MODULARITY
The NMRVpower series allows to a single basic unit to install bush and flange that correspond to different motor sizes.
The basic unit can be purchased alone if it is a replacement of another NMRV-Power Series VSF, reusing the currently installed bushing and flange.
For the purchase of a new complete unit, it is instead necessary to purchase the bushing and flange relating to the motor to be installed.
The same applies to the use of HW pre-stages
Mounting position: B3
Oil plugs: No plugs (Standard)
Fornito completo di lubrificante a vita, olio a base sintetica, ENI TELIUM VSF per posizione di montaggio B3.
Output oil seal: NBR-Nitrile
Input oil seal: ACM-Polyacrylate
Output bearings: Ball bearings
Input bearings: Ball-Ball bearings
Lubrication: Eni Telium VSF 320
Paint: Ral 5010 blue
FEATURES:
Casing kit NMRV-P110 20,0 D42 B3 MV
Worm Gearbox: NMRV Power
Size: 110
Ratio (i): 20
Hollow output shaft dim.: D.42
MODULARITY
The NMRVpower series allows to a single basic unit to install bush and flange that correspond to different motor sizes.
The basic unit can be purchased alone if it is a replacement of another NMRV-Power Series VSF, reusing the currently installed bushing and flange.
For the purchase of a new complete unit, it is instead necessary to purchase the bushing and flange relating to the motor to be installed.
The same applies to the use of HW pre-stages
Mounting position: B3
Oil plugs: No plugs (Standard)
Fornito completo di lubrificante a vita, olio a base sintetica, ENI TELIUM VSF per posizione di montaggio B3.
Output oil seal: NBR-Nitrile
Input oil seal: ACM-Polyacrylate
Output bearings: Ball bearings
Input bearings: Ball-Ball bearings
Lubrication: Eni Telium VSF 320
Paint: Ral 5010 blue
List of combined products
AVAILABLE
M2006540
COP.RITEGNO BUSHING PAM NMRV-P090-110
COP.RITEGNO BUSHING PAM NMRV-P090-110
€ 2,10
COMING SOON
M2006541
COP.RITEGNO BUSHING PAM D38 NMRV-P110
COP.RITEGNO BUSHING PAM D38 NMRV-P110
€ 2,10
AVAILABLE
M2516383
BUSHING PAM NMRV-P110 D. 19
BUSHING PAM NMRV-P110 D. 19
€ 24,60
LIMITED AVAILABILITY
M2516388
BUSHING PAM NMRV-P110 D. 38
BUSHING PAM NMRV-P110 D. 38
€ 24,60
LIMITED AVAILABILITY
M3006942
GR.FLANGE USC.VSF105-11 0 FA 280 VER
GR.FLANGE USC.VSF105-11 0 FA 280 VER
€ 68,50
LIMITED AVAILABILITY
M3006943
GR.FLANGE USC.VSF105-11 0 FB 280 VER
GR.FLANGE USC.VSF105-11 0 FB 280 VER
€ 97,90
LIMITED AVAILABILITY
M3016725
GR. TORQUE ARM VSF 105-110
GR. TORQUE ARM VSF 105-110
€ 68,50
LIMITED AVAILABILITY
M3043581
GR.ALB.COLL.HW040+NMRV-P 110 i=4,20
GR.ALB.COLL.HW040+NMRV-P 110 i=4,20
€ 50,90
LIMITED AVAILABILITY
M3043876
GR.CARC.PR.HW040 3,11 19 U MV
GR.CARC.PR.HW040 3,11 19 U MV
€ 133,40
AVAILABLE
M3043978
KIT FLANGE PAM NMRV-P09 0/110 D120 B14 VER
KIT FLANGE PAM NMRV-P09 0/110 D120 B14 VER
€ 34,90
AVAILABLE
M3044009
KIT FLANGE PAM NMRV-P09 0/110 D.140 B14 VER
KIT FLANGE PAM NMRV-P09 0/110 D.140 B14 VER
€ 34,90
LIMITED AVAILABILITY
M3044010
KIT FLANGE PAM NMRV-P09 0/110 D160 B14 VER
KIT FLANGE PAM NMRV-P09 0/110 D160 B14 VER
€ 34,90
