PRODUCT details
9.602.014.01
GEARBOX 2.92 M-27.2 R -12.5 A-3A
GEARBOX 2.92 M-27.2 R -12.5 A-3A
€ 681,59
LIMITED AVAILABILITY
Shipment Costs
-
Trasporto a mezzo corriere Bartolini BRT 0,00 €
Product details
MANUFACTURER: COMER INDUSTRIES S.P.A.
Model: A-3A
Technical features:
Type of application:
Reduction gear unit
Input power rate: 17Cv-12.5Kw (540RPM)
Speed increasing unit
Input power rate: 37Cv-27.2Kw (540RPM)
Ratio: 2,92
Outputs: 1
Rotation
The rotation is defined as either clocwise or counter-clockwise by looking "into" the components in motion ( shaft, pulley, or sprocket), with the gearbox behind the component
Shafts Rotation: Download data sheet to check the possible available rotation.
Material: Cast iron
Dry weight: Kg 18
Supplied without lubricant
• Different shafts rotation available (please ask our TECHNICAL DEPARTMENT)
Model: A-3A
Technical features:
Type of application:
Reduction gear unit
Input power rate: 17Cv-12.5Kw (540RPM)
Speed increasing unit
Input power rate: 37Cv-27.2Kw (540RPM)
Ratio: 2,92
Outputs: 1
Rotation
The rotation is defined as either clocwise or counter-clockwise by looking "into" the components in motion ( shaft, pulley, or sprocket), with the gearbox behind the component
Shafts Rotation: Download data sheet to check the possible available rotation.
Material: Cast iron
Dry weight: Kg 18
Supplied without lubricant
• Different shafts rotation available (please ask our TECHNICAL DEPARTMENT)
